Katariya Steel is an ASTM A335 P5 Pipe Manufacturer and Supplier in India, offering Alloy Steel P5 seamless pipes for high-temperature and high-pressure industrial applications. Our ASTM A335 P5 pipes are available in different sizes, schedules, wall thicknesses and lengths, supported with relevant inspection and test documentation.
| Specifications | ASTM A335 P5 / ASME SA335 P5 |
|---|---|
| Standard | ASTM A335 / ASME SA335 |
| Dimensions | ASTM, ASME & API |
| Outside Diameter | 6–2500 mm |
| Wall Thickness | 0.3–50 mm |
| Size | 1/8" NB to 30" NB |
| Type | Seamless |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Beveled End & Threaded End |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS & All Schedules |
| Inspection & Test Reports | Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Reports & Non-Destructive Test Reports |
| Packing | Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled or as per Customer Requirements |
| Specials | Sizes and specifications other than those listed can be manufactured on request |
| Grade | C | Mn | Si | P | S | Cr | Mo |
| ASTM A335 P5 | 0.15 max | 0.30–0.60 | 0.50 max | 0.025 max | 0.025 max | 4.00–6.00 | 0.44-0.65 |
| Grade | Tensile Strength | Yield Strength | Elongation |
| ASTM A335 P5 | 415 MPa min | 205 MPa min | 30% min |
| NPS | Outside Diameter (mm) | SCH 40 WT (mm) | SCH 80 WT (mm) | SCH 160 WT (mm) |
| 1/8" | 10.3 | 1.73 | 2.41 | 3.15 |
| 1/4" | 13.7 | 2.24 | 3.02 | 3.99 |
| 3/8" | 17.1 | 2.31 | 3.20 | 4.78 |
| 1/2" | 21.3 | 2.77 | 3.73 | 4.78 |
| 3/4" | 26.7 | 2.87 | 3.91 | 5.54 |
| 1" | 33.4 | 3.38 | 4.55 | 6.35 |
| 1 1/4" | 42.2 | 3.56 | 4.85 | 6.35 |
| 1 1/2" | 48.3 | 3.68 | 5.08 | 7.14 |
| 2" | 60.3 | 3.91 | 5.54 | 8.74 |
| 2 1/2" | 73.0 | 5.16 | 7.01 | 9.53 |
| 3" | 88.9 | 5.49 | 7.62 | 11.13 |
| 4" | 114.3 | 6.02 | 8.56 | 13.49 |
| 6" | 168.3 | 7.11 | 10.97 | 18.26 |
| 8" | 219.1 | 8.18 | 12.70 | 23.01 |
| 10" | 273.0 | 9.27 | 12.70 | 31.75 |
| 12" | 323.9 | 9.53 | 12.70 | 35.71 |
ASTM A335 P5 pipes are chromium-molybdenum alloy steel seamless pipes designed for elevated-temperature service. The chromium and molybdenum content contributes to the material's strength and performance in demanding high-temperature and high-pressure piping systems.
The seamless construction and alloy composition make ASTM A335 P5 pipes suitable for applications where resistance to elevated temperatures, pressure and long-term service conditions is important. These pipes are widely used in industrial systems requiring reliable alloy steel piping for demanding operating environments.
ASTM A335 P5 alloy steel pipes are commonly used in industrial applications involving elevated temperatures and pressure, including:
Katariya Steel supplies ASTM A335 P5 alloy steel pipes for industrial and project requirements, with attention to applicable specifications, dimensions, tolerances and material traceability. Its quality-control process combines technical knowledge of industry standards with inspection procedures aimed at checking both physical and metallurgical aspects of supplied products.
The company also states that it performs raw-material certificate checks along with chemical and mechanical inspection, maintains traceability records through the production and supply process, and carries out visual inspection to identify deformation or damage.
Katariya Steel presents itself as a manufacturer, exporter, supplier and stockist of ASTM A335 P5 alloy steel pipes. Its existing P5 page covers seamless pipes in different sizes, schedules, lengths and configurations, along with inspection and test documentation listed in its product specifications.
For industrial and project requirements, ASTM A335 P5 pipes can be supplied across selected locations in India, covering requirements for seamless pipe configurations and related P5 material specifications.
Katariya Steel supplies and exports ASTM A335 P5 alloy steel pipes for international industrial and project requirements. The existing Katariya P5 page identifies the company as an exporter and includes international supply coverage for its alloy steel pipe products.
Japan
Russia
United States
Saudi Arabia
Kuwait
Singapore
Malaysia
Germany
Italy
China
United Kingdom
Canada
Iran
Thailand
South Korea
Turkey
Egypt
Oman
Australia
Qatar
Mexico
Brazil
France
South
Africa
Spain
Netherlands
Indonesia
Nigeria
Bangladesh
Looking for ASTM A335 P5 alloy steel pipes for an industrial or project requirement? Share your required pipe size, schedule or wall thickness, quantity, required test certificates and delivery location with Katariya Steel for a quotation.
